SSCC Barcode Generator

Make an SSCC barcode for a pallet or carton online for free. Enter the extension digit, your GS1 Company Prefix and a serial reference, and the generator adds the check digit and encodes the 18-digit SSCC as AI (00) in GS1-128, checked with GS1's syntax engine. Download SVG, PNG, PDF or EPS.

Valid

87.1 × 37.2 mm at 300 DPI

SSCC from your company prefix

Enter your 4- to 12-digit company prefix and a serial reference; the check digit is calculated.

Application Identifiers

  1. SSCC: Serial Shipping Container Code (SSCC). Format N18; predefined length, no FNC1 needed.

Moving AIs with a predefined length, such as (01) and (17), to the front saves FNC1 separators.

Check GS1 dataPaste and load

Write the group separator as {GS}. Valid data replaces the AI rows.

Symbology and content

The element strings in bracket notation. The brackets are not encoded; the generator adds FNC1 where GS1 requires it: 22 characters.

Size and resolution

Output DPI

300 DPI · Thermal / offset

6 px per module at 300 DPI. Print size: 87.1 × 37.2 mm (3.43 × 1.46 in). PNG, WebP and JPEG: 1056 × 451 px.

Human-readable text

Text size and alignment

Alignment

Text font

FontNew

Label textNew

Font

Alignment

Printed in the file with the barcode, outside the quiet zone, in Helvetica or Courier so it looks the same in every format.

Colors

Contrast 21.0:1; estimated symbol contrast 100%.

Quiet zone (modules)2 · 10 · 2 · 10

Bar width reduction0 mil

Makes each bar thinner by this amount, to make up for ink that spreads on paper. Ask your printer for the value, or leave 0 for laser and thermal printing.

Rotation and backgroundNew0° · Filled

Rotation

In the preview, a checkered pattern shows the transparent areas. Print a transparent barcode only on a white or very light surface: scanners need the light quiet zone around it.

Margin and borderNew0 mm · no border

The margin is blank space outside the quiet zone, for cutting; the border is drawn at the outer edge. Both count in the print size.

Data inspectorNew22 chars
PresetsNew0 saved

No presets yet. Save the current settings to reuse them.

    Presets stay in this browser. They keep the type, size and style; the data and the logo are not saved.

    Recent barcodesNew0

    The barcodes you download appear here, newest first.

      The last 10 downloads, kept in this browser only.
      GS1-128 · Live previewValid
      GS1-128 barcode encoding (00)106141411234567897
      New

      Scaled to fit. Actual size shows the print size on screen.

      Print simulationNew

      Shows how a worn print looks and tests it with the decoder.

      Type
      GS1-128 · 1D
      Print size
      87.1 × 37.2 mm
      Raster
      1056 × 451 px

      Valid GS1 data: 1 element string, checked with GS1's Barcode Syntax Engine 1.4.1.

      Message with FNC1

      FNC100106141411234567897

      What a scanner sends

      ]C100106141411234567897

      GS1 Digital Link URI

      https://id.gs1.org/00/106141411234567897

      A valid structure is not GS1 certification: the GTIN or SSCC must come from your own GS1 Company Prefix, licensed by GS1.

      The check runs on your device with the GS1 Barcode Syntax Engine 1.4.1, © GS1 AISBL, under the Apache License 2.0.

      Download

      Vector drawing, 87.1 × 37.2 mm. Design and label programs place it at its print size.

      More export optionsNewTest sheet · size set · embed code

      Print test sheet (PDF)

      The code at 80%, 100% and 150% with 100 mm and 4 in rulers. Print it at actual size and scan each copy before printing many.

      Size set (ZIP)

      Magnification

      Embed code

      Nothing you type is uploaded.New

      How to Make an SSCC Barcode

      Build the SSCC from your company prefix, put it in AI (00), and download the GS1-128 barcode.

      1. Choose an extension digit from 0 to 9.
      2. Enter your GS1 Company Prefix and a serial reference you have not used for another unit.
      3. Check the SSCC and its check digit, then choose Put the SSCC in AI (00).
      4. Add other AIs if your label needs them, then download the barcode and scan a test print.

      SSCC Number Structure

      An SSCC has 18 digits: an extension digit, a GS1 Company Prefix, a serial reference and a check digit.

      The Four Parts

      • Extension digit: 0 to 9, assigned by the company that builds the SSCC to increase the capacity of the serial reference.
      • GS1 Company Prefix: 4 to 12 digits from a GS1 Member Organization; it makes the SSCC unique but does not show where the unit comes from.
      • Serial reference: the remaining digits up to the 17th, chosen by the prefix owner to identify each logistic unit.
      • Check digit: the 18th digit, calculated from the first 17.

      SSCC Example

      The SSCC 106141411234567897 has extension digit 1, the example company prefix 0614141 used in GS1's General Specifications, serial reference 123456789 and check digit 7. As an element string it is written (00)106141411234567897.

      GS1-128 barcode with the SSCC (00) 106141411234567897: extension digit 1, company prefix 0614141, serial reference 123456789 and check digit 7.
      SSCC 106141411234567897 in a GS1-128 barcode, AI (00).

      SSCC Check Digit Calculator

      The SSCC check digit is the GS1 mod 10 digit: weights of 3 and 1 alternate from the right, and the digit brings the sum up to a multiple of 10.

      How the Helper Uses It

      The SSCC helper calculates the check digit as you type, and the syntax check rejects an SSCC whose last digit is wrong. GS1 states that the check digit must be verified by application software.

      SSCC Labels on Pallets and Cartons

      The SSCC identifies one logistic unit, such as a pallet or a carton, and goes on its label as AI (00) in a GS1-128 barcode.

      One SSCC for Each Logistic Unit

      The serial reference is chosen to identify each logistic unit uniquely. Keep a record of the numbers you have used, because this generator does not store or track them.

      Contents and Count

      A label can add the GTIN of the contents with (02) and their count with (37). GS1's syntax dictionary only allows (02) with (37), and (37) with (00) and either (02) or (8026); the check reports these rules.

      GS1-128 barcode with the SSCC (00) 106141411234567897, the GTIN of the contents (02) 10614141000415 and the count (37) 24.
      SSCC with the contents (02) and their count (37).

      AIs Used With the SSCC

      These logistics and shipping AIs can share a barcode with the SSCC when their pairing rules allow it.

      Format: N is a digit; X, Y and Z are characters from GS1's character sets 82, 39 and 64; ".." means up to that many; brackets mark an optional part.

      GS1 Application Identifiers
      AIData titleDescriptionFormatFNC1 after it
      (00)SSCCSerial Shipping Container Code (SSCC)N18No
      (02)CONTENTGlobal Trade Item Number (GTIN) of contained trade itemsN14No
      (37)COUNTCount of trade items or trade item pieces contained in a logistic unitN..8Yes, unless last
      (400)ORDER NUMBERCustomers purchase order numberX..30Yes, unless last
      (401)GINCGlobal Identification Number for Consignment (GINC)X..30Yes, unless last
      (403)ROUTERouting codeX..30Yes, unless last
      (410)SHIP TO LOCShip to / Deliver to Global Location Number (GLN)N13No
      (413)SHIP FOR LOCShip for / Deliver for - Forward to Global Location Number (GLN)N13No
      (420)SHIP TO POSTShip to / Deliver to postal code within a single postal authorityX..20Yes, unless last
      (421)SHIP TO POSTShip to / Deliver to postal code with ISO country codeN3+X..9Yes, unless last

      Sources: GS1 Barcode Syntax Dictionary, release 2026-01-27, and the GS1 Application Identifiers vocabulary, version 1.2.

      Frequently Asked Questions

      What Is an SSCC?

      SSCC stands for Serial Shipping Container Code, the GS1 key for a logistic unit such as a pallet or a parcel. It has 18 digits and is encoded with AI (00).

      Where Do I Get a GS1 Company Prefix?

      From a GS1 Member Organization, such as GS1 US in the United States. Barcode.codes does not issue prefixes or SSCCs, and a number that passes the check is not a registration.

      What Is the Extension Digit For?

      It adds a digit of capacity to the serial reference. The company that builds the SSCC assigns it, from 0 to 9.

      What Does SSCC-18 Mean?

      People write SSCC-18 because the SSCC has 18 digits; GS1 simply calls it the SSCC. The generator encodes exactly 18 digits in AI (00).

      Can the Generator Number Many Pallets in a Row?

      No. It makes one SSCC at a time and does not remember serial references, so track your numbers in your own system.

      Can I Put an SSCC in GS1 DataMatrix?

      This page draws GS1-128. The GS1 DataMatrix generator accepts the same (00) element string if your trading partner asks for a 2D code.
